Sale! -14%

Yealink EXP40 LCD Expansion Module

RM441.99

Yealink EXP40 LCD Expansion Module

  • The EXP40 Expansion Module for the SIP-T46S, SIP-T46G, SIP-T48S and SIP-T48G.
  • Expanding the functional capability of your sip phone to a whole new level.
  • Equipped with a 160×320 graphic LCD with Backlight. 20 physical keys each with a dual-color LED and two page views are possible.
  • Supports up to 6 Expansion Modules for an attendant console application, adding up to 240 additional buttons.
  • Two pages of 20 flexible buttons are shown on the display can be programmed up to 40 various features, the productivity-enhancing features include BLF/BLA, speed dialing, call forward, transfer, park, pickup, etc.
Categories: , Tag:

Description

Yealink EXP40 Expansion Module features two pages of 20 flexible physical buttons that can be programmed for various features including BLF/BLA, speed dialing, call forward, call transfer, pickup call, and many more to help increase productivity.

It supports up to 6 Expansion Modules for a console application, which adding up to 240 additional buttons. However, it has to be powered by a traditional power supply (5V/1.2A) if there is more than 3 connections.

Yealink EXP40 LCD Expansion Module:

Features

  • An exclusive collection which quality and detailed designs
  • Rich visual experience with 160×320 graphic LCD supports16-level grayscales
  • LCD Backlight
  • Two page views are possible
  • Different icons for each function shown on the LCD
  • 20 physical keys each with a dual-color LED
  • 2 independent control keys are used for fast switch pages
  • Stand with 2 adjustable angles
  • Wall mountable

Features Keys and Indicator

  • 20 physical keys each with a dual-color LED
  • 20 additional keys through page switch
  • 2 independent control keys are used for fast
    switch pages
  • Programmable for Shared Line, BLF List,
    BroadSoft Group, Call Park, Conference,
    Forward, Group pickup Group listening,
    LDAP, Pick UP, XML Browser, Zero-SP-Touch…

Physical Feature

  • Wall mountable
  • Stand with 2 adjustable angles
  • Expansion module (≤2) is powered by the
    host phone
  • Supports up to 6 modules daisy-chain
  • 2xRJ12(6P6C)ports for data in and out
  • Dimension (W*D*H*T):
  • 127mm*213mm*167mm*45mm
  • Applies to Yealink IP Phone
  • Operating temperature: -10~50°C
  • Operating humidity: 10-95%

Additional information

Weight 0.67 kg
Dimensions 21.3 × 12.7 × 4.5 cm
